A photorealistic image of a Perrot coupling mounted within a square aluminum frame on a green chain-link fence with barbed wire.

A photorealistic image of a Perrot coupling mounted within a square aluminum frame on a green chain-link fence with barbed wire.

Das Gesamtbild: Inmitten des grünen oder verzinkten Maschendrahtzauns sitzt auf Augenhöhe (oder in Bodennähe) ein perfekt quadratischer, silbern glänzender Aluminiumrahmen von 30 x 30 cm. Der Rahmen fügt sich bündig in die Flucht des Zauns ein.Die Zaunanbindung: Die Maschen des Zauns hören links und rechts nicht einfach auf, sondern die sauber gekappten Drahtenden sind stramm um das Aluminiumprofil gewickelt oder mit glänzenden Gripple-Drahtspannern an kleinen Ösen am Rahmen fixiert. Der Zaun hängt dadurch an keiner Stelle durch.Das Zentrum: Genau in der Mitte des Rahmens ragt das massive, verzinkte Stahlrohr des Perrot-DN100-Stutzens nach vorne heraus.Die Halterung: Das Rohr schwebt nicht frei, sondern wird von einer massiven, schwarzen Gummieinlage einer robusten Rohrschelle umschlossen. Die Schelle selbst ist über eine Gewindestange oder ein Flacheisen bombenfest mit der Ober- und Unterseite des Alurahmens verschraubt.Die Kupplung: Auf der Vorderseite des Zauns sehen Sie nun entweder das markante Perrot-M-Teil (den runden "Kopf" mit der Dichtung) oder das V-Teil. Da Sie 30 cm Platz gewählt haben, ist um die beiden großen Schließhebel herum genug Luft, sodass man sie bequem mit den Händen greifen und umlegen kann, ohne das Aluminium oder den Zaun zu berühren. See more
